MB95160M

• F²MC-8FX CPU core Instruction set optimized for controllers
• Multiplication and division instructions
• 16-bit arithmetic operations
• Bit test branch instruction
• Bit manipulation instructions etc.
• Clock
• Main clock
• Main PLL clock
• Sub clock
• Sub PLL clock
• Timer
• 8/16-bit compound timer × 2 channels
Can be used to interval timer, PWC timer, PWM timer and input capture.
• 8/16-bit PPG × 2 channels
• 16-bit PPG × 1 channel
• Time-base timer × 1 channel
• Watch prescaler × 1 channel
• LIN-UART × 1 channel
• LIN function, clock asynchronous (UART) or clock synchronous (SIO) serial data transfer capable
• Full duplex double buffer
• UART/SIO × 1 channel
• Clock asynchronous (UART) or clock synchronous (SIO) serial data transfer capable
• Full duplex double buffer
• I²C* × 1 channel Built-in wake-up function
• External interrupt × 8 channels
• Interrupt by edge detection (rising, falling, or both edges can be selected)
• Can be used to recover from low-power consumption (standby) modes.
• 8/10-bit A/D converter × 8 channels 8-bit or 10-bit resolution can be selected.
• LCD controller (LCDC)
• 32 SEG × 4 COM (Max 128 pixels)
• With blinking function
• Low-power consumption (standby) mode
• Stop mode
• Sleep mode
• Watch mode
• Time-base timer mode
• I/O port
• The number of maximum ports : Max 53
• Port configuration
- General-purpose I/O ports (N-ch open drain) : 2 ports
- General-purpose I/O ports (CMOS) : 51 ports
• Programmable input voltage levels of port Automotive input level / CMOS input level / hysteresis input level
• Flash memory security function Protects the content of Flash memory
* : Purchase of Fujitsu I2C components conveys a license under the Philips I2C Patent Rights to use, these components in an I2C system provided that the system conforms to the I2C Standard Specification as defined by Philips.

The MB95160M series is general-purpose, single-chip microcontrollers. In addition to a compact instruction set,the microcontrollers contain a variety of peripheral functions.
Note : F²MC is the abbreviation of FUJITSU Flexible Microcontroller.
