MB252

Power Dissipation :
Product : Single Phase Bridge
Forward Continuous Current : 25 A
Maximum Operating Temperature : + 150 C
Length : 30 mm
Mounting Style : Through Hole
Forward Voltage Drop : 1.1 V
Maximum Reverse Leakage Current : 5 uA
Max Surge Current : 300 A
Packaging : Bulk
Peak Reverse Voltage : 200 V
Maximum RMS Reverse Voltage : 140 V
Width : 30 mm
Height : 11.5 mm
Package / Case : MB-25


Features:

· Mounting Hole For #8 Screw
· High Conductivity Metal Case
· Any Mounting Position
· Surge Rating Of 300 Amps




Specifications

· Operating Temperature: -55°C to +125°C
· Storage Temperature: -55°C to +150°C

MCC	Device	Maximum	Maximum	Maximum
Catalog	Marking	Recurrent	RMS	DC
Number		Peak Reverse	Voltage	Blocking
		Voltage		Voltage
MB2505	MB2505	50V	35V	50V
MB251	MB251	100V	70V	100V
MB252	MB252	200V	140V	200V
MB254	MB254	400V	280V	400V
MB256	MB256	600V	420V	600V
MB258	MB258	800V	560V	800V
MB2510	MB2510	1000V	700V	1000V

Parameters:

Technical/Catalog Information	MB252
Vendor	Diodes Inc
Category	Discrete Semiconductor Products
Diode Type	Single Phase
Package / Case	MB
Packaging	Bulk
Reverse Recovery Time (trr)	-
Speed	Standard Recovery >500ns, > 200mA (Io)
Current - DC Forward (If)	25A
Voltage - Peak Reverse (Max)	200V
Mounting Type	QC Terminal
Lead Free Status	Lead Free Compliant by Exemption
RoHS Status	RoHS Compliant
Other Names	MB252 MB252 MB252DI ND MB252DIND MB252DI
