M25P20

Features: • 2 Mbit of Flash Memory• Page Program (up to 256 Bytes) in 1.5ms (typical)• Sector Erase (512 Kbit) in 2 s (typical)• Bulk Erase (2 Mbit) in 3 s (typical)• 2.7 V to 3.6 V Single Supply Voltage• SPI Bus Compatible Serial Interface• 25 MHz Clock R...

product image

M25P20 Picture
See larger image
SeekIC No. : 004404183 Detail

M25P20: Features: • 2 Mbit of Flash Memory• Page Program (up to 256 Bytes) in 1.5ms (typical)• Sector Erase (512 Kbit) in 2 s (typical)• Bulk Erase (2 Mbit) in 3 s (typical)• 2...

M25P20 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
M25P20
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/27

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 2 Mbit of Flash Memory
• Page Program (up to 256 Bytes) in 1.5ms (typical)
• Sector Erase (512 Kbit) in 2 s (typical)
• Bulk Erase (2 Mbit) in 3 s (typical)
• 2.7 V to 3.6 V Single Supply Voltage
• SPI Bus Compatible Serial Interface
• 25 MHz Clock Rate (maximum)
• Deep Power-down Mode 1 µA (typical)
• Electronic Signature (11h)
• More than 100,000 Erase/Program Cycles per Sector
• More than 20 Year Data Retention


Pinout

Connection Diagram


Specifications

Symbol

Parameter                                                                                    Min.

 Max Unit

TSTG

 Storage Temperature

 -65

 150

TLEAD

 Lead Temperature during Soldering                SO
(20 seconds max.)1                                         VFQFPN

235

  235



VIO

 Input or Output Voltages (with respect to Ground)  -0.6 4.0 V

VCC

 Supply Voltage -0.6

4.0

 V

VESD

Electrostatic Discharge Voltage (Human Body model)2

 -2000  200 V
Note: 1. IPC/JEDEC J-STD-020A
          2. JEDEC Std JESD22-A114A (C1=100 pF, R1=1500 , R2=500 )


Description

The M25P20 is a 2 Mbit (256K x 8) Serial Flash Memory, with advanced write protection mechanisms,accessed by a high speed SPI-compatible bus.

The memory can be programmed 1 to 256 bytes at a time, using the Page Program instruction.

The memory M25P20 is organized as 4 sectors, each containing 256 pages. Each page is 256 bytes wide.Thus, the whole memory can be viewed as consisting of 1024 pages, or 262,144 bytes.

The whole memory M25P20 can be erased using the Bulk Erase instruction, or a sector at a time, using the Sector Erase instruction.
