LH530800A

` 131,072 words*8 bit organization
` Access time: 150 ns (MAX.)
` Power consumption:
    Operating: 192.5 mW (MAX.)
    Standby: 550 W (MAX.)
` Static operation
` TTL compatible I/O
` Three-state outputs
` Single +5 V power supply
` Packages:
    32-pin, 600-mil DIP
    32-pin, 525-mil SOP
    32-pin, 450-mil QFJ (PLCC)
` JEDEC standard EPROM pinout (DIP)

The LH530800A is a mask-programmable ROM organized as 131,072×8 bits (1,048,576 bits). It is fabricated using silicon-gate CMOS process technology.
