MOSFET 200V N-Channel a-FET Logic Level
IRLM210ATF: MOSFET 200V N-Channel a-FET Logic Level
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Transistor Polarity : | N-Channel | Drain-Source Breakdown Voltage : | 200 V | ||
Gate-Source Breakdown Voltage : | +/- 20 V | Continuous Drain Current : | 0.77 A | ||
Resistance Drain-Source RDS (on) : | 1.5 Ohms | Configuration : | Single | ||
Maximum Operating Temperature : | + 150 C | Mounting Style : | SMD/SMT | ||
Package / Case : | SOT-223 | Packaging : | Reel |
Technical/Catalog Information | IRLM210ATF |
Vendor | Fairchild Semiconductor |
Category | Discrete Semiconductor Products |
Mounting Type | Surface Mount |
FET Polarity | N-Channel |
Drain to Source Voltage (Vdss) | 200V |
Current - Continuous Drain (Id) @ 25° C | 770mA |
Rds On (Max) @ Id, Vgs | 1.5 Ohm @ 390mA, 5V |
Input Capacitance (Ciss) @ Vds | 240pF @ 25V |
Power - Max | 1.8W |
Packaging | Tape & Reel (TR) |
Gate Charge (Qg) @ Vgs | 9nC @ 5V |
Package / Case | SOT-223, SC-73, TO-261 (3 Leads + Tab) |
FET Feature | Standard |
Lead Free Status | Lead Free |
RoHS Status | RoHS Compliant |
Other Names | IRLM210ATF IRLM210ATF |
