IRFP4468PBF

MOSFET MOSFT 100V 290A 2.6mOhm 360nC Qg

product image

IRFP4468PBF Picture
See larger image
SeekIC No. : 00152254 Detail

IRFP4468PBF: MOSFET MOSFT 100V 290A 2.6mOhm 360nC Qg

IRFP4468PBF Data Sheet

floor Price/Ceiling Price

US $ 2.6~4.67 / Piece | Get Latest Price
Part Number:
IRFP4468PBF
Mfg:
International Rectifier
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $4.67
  • $3.41
  • $2.7
  • $2.6
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Transistor Polarity : N-Channel Drain-Source Breakdown Voltage : 100 V
Gate-Source Breakdown Voltage : 20 V Continuous Drain Current : 290 A
Mounting Style : Through Hole Package / Case : TO-247AC
Packaging : Tube

Description

Resistance Drain-Source RDS (on) :
Configuration :
Maximum Operating Temperature :
Transistor Polarity : N-Channel
Drain-Source Breakdown Voltage : 100 V
Mounting Style : Through Hole
Packaging : Tube
Gate-Source Breakdown Voltage : 20 V
Package / Case : TO-247AC
Continuous Drain Current : 290 A


Application

·High Efficiency Synchronous Rectification in SMPS
·Uninterruptible Power Supply
·High Speed Power Switching
·Hard Switched and High Frequency Circuits


Specifications

Symbol Parameter Max. Units
ID @ TC = 25°C Continuous Drain Current, VGS @ 10V 290 A
ID TC =100°C Continuous Drain Current, VGS @ 10V 200 A
IDM Pulsed Drain Current 195 A
PD @ TC = 25 Maximum Power Dissipation 1120 W
  Linear Derating Factor

520

 W
VGS Gate-to-Source Voltage 3.4 W/
dv/dt Peak Diode Recovery ±20
TJ
TSTG		 Operating Junction and
Storage Temperature Range		 -55 to + 175
  Soldering Temperature, for 10 seconds
(1.6mm from case)		 300
  Mounting torque, 6-32 or M3 screw 10lb
in (1.1N
m)



Parameters:

Technical/Catalog InformationIRFP4468PBF
VendorInternational Rectifier
CategoryDiscrete Semiconductor Products
Mounting TypeThrough Hole
FET PolarityN-Channel
Drain to Source Voltage (Vdss)100V
Current - Continuous Drain (Id) @ 25° C195A
Rds On (Max) @ Id, Vgs2.6 mOhm @ 180A, 10V
Input Capacitance (Ciss) @ Vds 19860pF @ 50V
Power - Max520W
PackagingTube
Gate Charge (Qg) @ Vgs540nC @ 10V
Package / CaseTO-247AC
FET FeatureLogic Level Gate
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names IRFP4468PBF
IRFP4468PBF
