ICS83115

• 16 LVCMOS/LVTTL outputs
• 1 LVCMOS/LVTTL clock input
• Maximum output frequency: 200MHz
• All inputs are 5V tolerant
• Output skew: 250ps (maximum)
• Part-to-part skew: 800ps (maximum)
• Additive phase jitter, RMS: 0.09ps (typical)
• 3.3V operating supply
• 0°C to 70°C ambient operating temperature
• Lead-Free package available
• Industrial temperature information available upon request

The ICS83115 is a low skew, 1-to-16 LVCMOS/ LVTTL Fanout Buffer and a member of the HiPerClockS™ family of High Performance Clock Solutions from ICS. The ICS83115 single ended clock input accepts LVCMOS or LVTTL input levels. The ICS83115 operates at full 3.3V supply mode over the commercial temperature range. Guaranteed output and part-topart skew characteristics make the ICS83115 ideal for those clock distribution applications demanding well defined performance and repeatability.
