HWS411

Features: · Low Insertion Loss : 0.8 dB @ 2.5 GHz 1.0 dB @ 4.9 to 6.0 GHz· High Isolation: 43 dB @ 2.5 GHz 36 dB @ 4.9 to 6.0 GHz· Low DC Power Consumption· Miniature QFN12L (3x3 mm) Plastic Package· PHEMT processPinoutSpecifications Parameter Absolute Maximum RF Input Power +32 dBm @ +3...

product image

HWS411 Picture
See larger image
SeekIC No. : 004368020 Detail

HWS411: Features: · Low Insertion Loss : 0.8 dB @ 2.5 GHz 1.0 dB @ 4.9 to 6.0 GHz· High Isolation: 43 dB @ 2.5 GHz 36 dB @ 4.9 to 6.0 GHz· Low DC Power Consumption· Miniature QFN12L (3x3 mm) Plastic Package...

HWS411 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HWS411
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

· Low Insertion Loss : 0.8 dB @ 2.5 GHz
                                   1.0 dB @ 4.9 to 6.0 GHz
· High Isolation: 43 dB @ 2.5 GHz
                          36 dB @ 4.9 to 6.0 GHz
· Low DC Power Consumption
· Miniature QFN12L (3x3 mm) Plastic Package
· PHEMT process


Pinout

Connection Diagram


Specifications

Parameter Absolute Maximum
RF Input Power +32 dBm @ +3V
Control Voltage +6V
Operating Temperature -40 to +85
Storage Temperature -65to +150



Description

The HWS411 is a GaAs PHEMT MMIC DPDT switch operating at DC-6 GHz in a low cost miniature QFN12L (3 x 3 mm) plastic package. The features low insertion loss and high isolation up to 6 GHz with very low DC power consumption. This switch can be used in IEEE 802.11a/b/g WLAN systems for combination of transmit/receive and antenna diversity functions.
