HLMP-1790

Standard LED - Through Hole Green Diffused 565nm 2.3mcd

product image

HLMP-1790 Picture
See larger image
SeekIC No. : 0053843 Detail

HLMP-1790: Standard LED - Through Hole Green Diffused 565nm 2.3mcd

HLMP-1790 Data Sheet

floor Price/Ceiling Price

US $ .11~.3 / Piece | Get Latest Price
Part Number:
HLMP-1790
Mfg:
Avago Technologies
Supply Ability:
5000

Price Break

  • Qty
  • 0~1
  • 1~25
  • 25~100
  • 100~250
  • Unit Price
  • $.3
  • $.14
  • $.12
  • $.11
  • Processing time
  • 15 Days
  • 15 Days
  • 15 Days
  • 15 Days
View more price & deliveries
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Quick Details

Illumination Color : Green Luminous Intensity : 2.3 mcd
Wavelength/Color Temperature : 569 nm Viewing Angle : 50 deg
Lens Color/Style : Tinted, Diffused Forward Current : 2 mA
LED Size : T-1 Packaging : Bulk

Description

Forward Voltage :
Illumination Color : Green
LED Size : T-1
Packaging : Bulk
Lens Color/Style : Tinted, Diffused
Forward Current : 2 mA
Wavelength/Color Temperature : 569 nm
Luminous Intensity : 2.3 mcd
Viewing Angle : 50 deg


Features:

• Low Power
• High Efficiency
• CMOS-MOS Compatible
• TTL Compatible
• Wide Viewing Angle
• Choice of Package Styles
• Choice of Colors




Application

• Low Power DC Circuits
• Telecommunications Indicators




Specifications

Parameter
Maximum Rating
Units
Power Dissipation
(Derate linearly from 92°C at 1.0 mA/°C)
Red
Yellow
Green
24
36
24
mW
DC and Peak Forward Current
7
mA
Transient Forward Current (10 ms Pulse) [1]
500
mA
Reverse Voltage (IR = 50 mA)
5.0
V
Operating Temperature Range
Red/Yellow
Green
-55°C to 100°C
-20°C to 100°C
Storage Temperature Range
-55°C to +100°C
Lead Soldering Temperature
[1.6 mm (0.063 in.) from body]
260°C for 5 seconds
Note:
1. The transient peak current is the maximum non-recurring peak current the devices can withstand without damaging the LED die and
wire bonds. It is not recommended that the device be operated at peak currents beyond the Absolute Maximum Peak Forward Current.




Description

This HLMP-1790 tinted diffused LED lamp is designed and optimized specifically for low current operation. Luminous intensity and forward voltage are tested at 2 mA to assure consistant brightness at TTL output current levels.






Parameters:

Technical/Catalog InformationHLMP-1790
VendorAvago Technologies US Inc.
CategoryOptoelectronics
ColorGreen
Lens Style/SizeRound, 3mm, T-1
Millicandela Rating2.3mcd
Voltage - Forward (Vf) Typ1.9V
Wavelength - Dominant569nm
Wavelength - Peak565nm
Current - Test2mA
Viewing Angle50°, 35°
Lens TypeDiffused, Green Tinted
Luminous Flux1 mlm, 1 mlm
Package / CaseRadial
Mounting TypeThrough Hole
PackagingBulk
Lead Free StatusLead Free
RoHS StatusRoHS Compliant
Other Names HLMP 1790
HLMP1790
516 1310 ND
5161310ND
516-1310
