HL1566AF

Features: ` Long wavelength output: p = 1550 nm Typ.` High extinction ratio: 13 dB Min. at VR(EA) = 2 V` Fast pulse response: tr/tf 80 ps` Dynamic single longitudinal mode: Sr = 40 dB Typ.` Package: open air package (chip on carrier) with micro strip-lineSpecifications Item Symbol Value Un...

product image

HL1566AF Picture
See larger image
SeekIC No. : 004362879 Detail

HL1566AF: Features: ` Long wavelength output: p = 1550 nm Typ.` High extinction ratio: 13 dB Min. at VR(EA) = 2 V` Fast pulse response: tr/tf 80 ps` Dynamic single longitudinal mode: Sr = 40 dB Typ.` Package:...

HL1566AF Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HL1566AF
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/7/15

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` Long wavelength output: p = 1550 nm Typ.
` High extinction ratio: 13 dB Min. at VR(EA) = 2 V
` Fast pulse response: tr/tf 80 ps
` Dynamic single longitudinal mode: Sr = 40 dB Typ.
` Package: open air package (chip on carrier) with micro strip-line


Specifications

Item Symbol Value Unit
LD forward current IF 100 mA
Laser diode reverse voltage VR (LD) 2 V
Modulator reverse voltagee VR(EA) -5 V
Operating temperature Topr 10 to +40
Storage temperature Tstg -40 to 85

Note: 1. without condensation




Description

The HL1566AF is a 1.55 m InGaAsP distributed-feedback laser diode (DFB-LD) with a multiquantum well (MQW) structure. An electroabsorption (EA) modulator is integrated with the laser diode. HL1566AF is suitable as a light source for high-bit-rate, long haul fiberoptic communication systems, such as 2.5 Gbps external modulation systems for up to 600 km.
