HGTG20N120E2

Features: • 34A, 1200V• Latch Free Operation• Typical Fall Time - 780ns• High Input Impedance• Low Conduction LossPinoutSpecificationsCollector-Emitter Breakdown Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . BVCES 1200 VCollector-Gate Breakdown Vo...

product image

HGTG20N120E2 Picture
See larger image
SeekIC No. : 004362155 Detail

HGTG20N120E2: Features: • 34A, 1200V• Latch Free Operation• Typical Fall Time - 780ns• High Input Impedance• Low Conduction LossPinoutSpecificationsCollector-Emitter Breakdown Voltag...

HGTG20N120E2 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
HGTG20N120E2
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/10/18

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• 34A, 1200V
• Latch Free Operation
• Typical Fall Time - 780ns
• High Input Impedance
• Low Conduction Loss


Pinout

Connection Diagram


Specifications

Collector-Emitter Breakdown Voltage. . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  BVCES 1200 V
Collector-Gate Breakdown Voltage RGE = 1MW. . . . . . . . . . . . . . . . . . . . . .  BVCGR 1200 V
Collector Current Continuous At TC = +25. . . . . . . . . . . . . . . . . . . . . . . . . . . . IC25 34 A
Collector Current Continuous At TC = +90. . . . . . . . . . . . . . . . . . . . . . . . . . . . .IC90 20A
Collector Current Pulsed (Note 1) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . ICM 100 A
Gate-Emitter Voltage Continuous. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . VGES ±20 V
Gate-Emitter Voltage Pulsed . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  VGEM ±30 V
Switching SOA at TC = +150 . . . . . . . . . . . . . . . . . . . . . . . . . . .SSOA 100A at 0.8 BVCES
Power Dissipation Total at TC = +25o . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .PD 150 W
Power Dissipation Derating TC > +25 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1.20 W/
Operating and Storage Junction Temperature . . . . . . . . . . . . . . . . TJ, TSTG -55 to +150
Maximum Lead Temperature for Soldering . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .TL 260
(0.125" from case for 5 seconds)
Short Circuit Withstand Time (Note 2)
At VGE = 15V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .tSC 3 s
At VGE = 10V . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  tSC 15 s


Description

The HGTG20N120E2 is a MOS gated, high voltage switching device combining the best features of MOSFETs and bipolar transistors. The HGTG20N120E2 has the high input impedance of a MOSFET and the low on-state conduction loss of a bipolar transistor. The much lower on-state voltage drop varies only moderately between +25 and +150.

HGTG20N120E2 IGBTs are ideal for many high voltage switching applications operating at frequencies where low conduction losses are essential, such as: AC and DC motor controls, power supplies and drivers for solenoids, relays and contactors.  The development type number for this device is TA49009.
