CS8156

Features: • Two Regulated Outputs 12 V ±5.0%; 750 mA 5.0 V ±2.0%; 100 mA• Very Low SLEEP Mode Current Drain 200 nA• Fault Protection Reverse Battery +60 V, 50 V Peak Transient Voltage Short Circuit Thermal Shutdown• CMOS Compatible ENABLESpecifications Rating Valu...

product image

CS8156 Picture
See larger image
SeekIC No. : 004316749 Detail

CS8156: Features: • Two Regulated Outputs 12 V ±5.0%; 750 mA 5.0 V ±2.0%; 100 mA• Very Low SLEEP Mode Current Drain 200 nA• Fault Protection Reverse Battery +60 V, 50 V Peak Transient Volt...

CS8156 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
CS8156
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/12/21

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• Two Regulated Outputs
12 V ±5.0%; 750 mA
5.0 V ±2.0%; 100 mA
• Very Low SLEEP Mode Current Drain 200 nA
• Fault Protection
Reverse Battery
+60 V, 50 V Peak Transient Voltage
Short Circuit
Thermal Shutdown
• CMOS Compatible ENABLE


Specifications

Rating
Value
Unit
Input Voltage: Operating Range
Peak Transient Voltage (Note 1.)
0.5 to 26
60
V
V
Internal Power Dissipation
Internally Limited
-
Operating Junction Temperature
40 to +125
°C
Junction Temperature Range
40 to +150
°C
Storage Temperature Range
65 to 150
°C
Lead Temperature Soldering: Wave Solder (through hole styles only) (Note 2.)
260 peak
°C
1. Load Dump = 46 V
2. 10 second maximum.
*The maximum package power dissipation must be observed.


Description

The CS8156 is a low dropout 12 V/5.0 V dual output linear regulator.The 12 V ±5.0% output sources 750 mA and the 5.0 V ±2.0% output sources 100 mA.

The on board ENABLE function controls the regulator's two outputs. When the ENABLE lead is low, the regulator is placed in SLEEP mode. Both CS8156 outputs are disabled and the regulator draws only 200 nA of quiescent current.

CS8156 regulator is protected against overvoltage conditions. Both outputs are protected against short circuit and thermal runaway conditions.

The CS8156 is packaged in a 5 lead TO220 with copper tab. The copper tab can be connected to a heat sink if necessary.
