COP8ACC5

Supply Voltage (V_CC) 7V
Voltage at Any Pin−0.3V to V_CC +0.3V
Total Current into V_CC Pin (Source) 100 mA
Total Current out of GND Pin (Sink) 110 mA
Storage Temperature Range−65°C to +140°C

The COP8ACC5 ROM based microcontrollers are highly integrated COP8™ Feature core devices with 4k memory and advanced features including a High-Resolution A/D. These single-chip CMOS devices are suited for applications requiring a full featured, low EMI controller with an A/D (only one external capacitor required). COP8ACC7 devices are pin and software compatible (different V_CC range) 16k OTP
EPROM versions for pre-production. Erasable windowed versions are available for use with a range of COP8 software and hardware development tools.

COP8ACC5 Family features include an 8-bit memory mapped architecture, 4 MHz CKI with 2.5s instruction cycle, 6 channel A/D with 12-bit resolution, analog capture timer, analog current source and V_CC/2 reference, one multi-function 16-bit timer/counter, MICROWIRE/PLUS serial I/O, two power saving HALT/IDLE modes, MIWU, high current outputs, software selectable I/O options,WATCHDOG™ timer and Clock Monitor,
Low EMI 2.5V to 5.5V operation and 20/28 pin packages.
