Product Details

Description



Pinout

Connection Diagram


Specifications

SYMBOL PARAMETER CONDITIONS
MIN.
MIN.
MIN.

VDS
VDGR
±VGS
ID
ID
IDM
Ptot
Tstg
Tj

 Drain-source voltage
Drain-gate voltage
Gate-source voltage
Drain current (DC)
Drain current (DC)
Drain current (pulse peak value)
Total power dissipation
Storage temperature
Junction Temperature		 -
RGS=20k
-
Ths = 25 °C
Ths = 100 °C
Ths = 25 °C
Ths = 25 °C
-
-

-
-
-
-
-
-
-
-55
-
200
200
30
V
V
V
A
A
A
W

-200A
19
12
76
-200B
17
11
68
125
150
150



Description

N-channel enhancement mode field-effect power transistor BUK436W-200B in a plastic envelope.

BUK436W-200B is intended for use in Switched Mode Power Supplies (SMPS), motor control, welding, DC/DC and AC/DC converters, and in general purpose switching applications.
