Features: · Very low RDS(on)· Direct interface to C-MOS, TTL· High-speed switching· No second breakdownSpecifications Drain-source voltage -VDS max. 60 V Gate-source voltage (open drain) ±VGSO max. 20 V Drain current (DC) -ID max. 0.25 A Drain current (peak) -IDM max. 0.5...
BST122: Features: · Very low RDS(on)· Direct interface to C-MOS, TTL· High-speed switching· No second breakdownSpecifications Drain-source voltage -VDS max. 60 V Gate-source voltage (open drain) ...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Drain-source voltage | -VDS | max. | 60 V |
Gate-source voltage (open drain) | ±VGSO | max. | 20 V |
Drain current (DC) | -ID | max. | 0.25 A |
Drain current (peak) | -IDM | max. | 0.5 A |
Total power dissipation up to Tamb = 25 (note 1) | Ptot | max. | 1 W |
Storage temperature range | Tstg | -65 to + 150 | |
Junction temperature | Tj | max. | 150 |
THERMAL RESISTANCE | |||
From junction to ambient (note 1) | Rth j-a | = | 125 K/W |
Note
1. Transistor mounted on a ceramic substrate: area = 2,5 cm2; thickness = 0,7 mm.
P-channel vertical D-MOS transistor BST122 in SOT89 envelope and intended for use in relay, high-speed and line-transformer drivers, using SMD-technology.
