Features: Very Low Dropout VoltageGuaranteed 300mA OutputAccurate to within 1.5%30µA Quiescent CurrentOver-Temperature ShutdownCurrent LimitingShort Circuit Current Fold-backSpace-Saving SOT-23, SOT-25, SOT-89 and TO-92 PackageFactory Pre-set Output VoltagesLow Temperature CoefficientApplica...
AME8811: Features: Very Low Dropout VoltageGuaranteed 300mA OutputAccurate to within 1.5%30µA Quiescent CurrentOver-Temperature ShutdownCurrent LimitingShort Circuit Current Fold-backSpace-Saving SOT-2...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Parameter | Maximum | Unit |
Input Voltage | 8 | V |
Output Current | PD/ (VIN- VO) | mA |
Output Voltage | GND - 0.3 to VIN + 0.3 | V |
ESD Classification | B |
The AME8800/8811 family of positive, linear regula-tors feature low quiescent current (30µA typ.) with low dropout voltage, making them ideal for battery applica-tions. The space-saving SOT-23, SOT-25, SOT-89 and TO-92 packages are attractive for "Pocket" and "Hand Held" aplications.These rugged devices have both Thermal Shutdown,and Current Fold-back to prevent device failure under the "Worst" of operating conditions.The AME8800/8811 is stable with an output capacitance of 2.2µF or greater.
