AME811R

Features:

100µV Resolution
High Impedance Differential Inputs
Differential Reference
Drive LCD Directly
Three New Convenient Features
(AME811A Only)
            Low-Battery Indication
            Integration Status Indication
            De-Integration Status Indication


Application

Digital multimeter
pH meter
Capacitance meter
Thermometer
Digital Panel meter
Photometer


Pinout




Specifications

Supply Voltage (V+ to V-)                                                                 12V
Analog Input Voltage (Either inputs)                                         V+ to V-
Reference Input Voltage (Either inputs)                                    V+ to V-
Clock Input Test to                                                                            V+
Power Dissipation                                                                     800mW
Operating Temperature                                                     0^oC to 70^oC
Storage Temperature                                                   -55^oC to 150^oC
Lead Temperature (Soldering 60 seconds)                                 300^oC


Description

The AME811 family are high performance, low power. 3-1/2 digit, dual-slope integrating A/D converters, with on-chip display drivers.  The AME811R is designed for a single battery operated system, will drive non-multiplexed LCD display directly.These A/D converters are inherently versatile and accurate.

They are immune to the high noise environments. The true differential high impedance inputs and differential reference are very useful for making ratiometric measurement, such as resistance, strain gauge and bridge transducers. The built-in auto-zero feature automatically corrects the system offset with- out any external adjustments.
