AK4182

Features: `12 bit SAR type A/D Converter with S/H circuit`Low Voltage Operation (VCC = 2.2V ∼ 3.6V)`Low Voltage Digital I/F (1.5V ∼ VCC)`4-wire I/F`Sampling Frequency: 125 kHz (max)`On-Chip Voltage Reference (2.5V)`Pen Pressure Measurement`On-Chip Thermo Sensor`Direct Battery Measureme...

product image

AK4182 Picture
See larger image
SeekIC No. : 004279292 Detail

AK4182: Features: `12 bit SAR type A/D Converter with S/H circuit`Low Voltage Operation (VCC = 2.2V ∼ 3.6V)`Low Voltage Digital I/F (1.5V ∼ VCC)`4-wire I/F`Sampling Frequency: 125 kHz (max)`On-C...

AK4182 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
AK4182
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/6/6

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

`12 bit SAR type A/D Converter with S/H circuit
`Low Voltage Operation (VCC = 2.2V ∼ 3.6V)
`Low Voltage Digital I/F (1.5V ∼ VCC)
`4-wire I/F
`Sampling Frequency: 125 kHz (max)
`On-Chip Voltage Reference (2.5V)
`Pen Pressure Measurement
`On-Chip Thermo Sensor
`Direct Battery Measurement
`Low Power Consumption (260A)
`Package 16pin QFN


Pinout

Connection Diagram


Specifications

Parameter Symbol Min max Units
Power Supplies VCC -0.3 6.0 V
Digital I/O Power Supply IOVDD -0.3 6.0 V
Input Current (any pins except for supplies) IIN - ±10 mA
Input Voltage VIN -0.3 6.0(VCC+0.3) V
Touch Panel Drive Current IOUTDRV   50 mA
Ambient Temperature (power supplied) Ta -40 85
Storage Temperature Tstg -65 150

Note 1.All voltages with respect to ground.

WARNING: Operation at or beyond these limits may result in permanent damage to the device.
                  Normal operation is not guaranteed at these extremes.


Description

The AK4182 is a 4-wire resistive touch screen controller that incorporates a 12-bit 125 kHz sampling SAR type A/D converter.

The AK4182 operates down to 2.2V supply voltage and supports digital I/O interface voltage from 1.5V to VCC in order to connect low voltage uP.

The AK4182 can detect the pressed screen location by performing two A/D conversions. In addition to location, the product also measures touch screen pressure.

On-chip VREF can be utilized for analog auxiliary input, temperature measurement and battery monitoring with the ability to measure voltage from 0V to 5V. The AK4182 also has an on-chip temperature sensor.The AK4182 is available in 16pin QFN thin package (0.75mm in height) and has the operating temperature range of -40 to +85.
