AIC3842

Supply Voltage (Low Impedance Source ) ................................. 30V
Supply Voltage (I_CC<300mA) ....................................... Self Limiting
Output Current .............. ......................................................... ±1A
Output Energy (Capacitive Load) .............................................. 5mJ
Analog Inputs (Pins 2, 3) ......................................... -0.3V to +6.3V
Error Amp Output Sink Current .............................................. 10mA
Operation Temperature Range ................................ -40°C~85°C
Power Dissipation at T_A 25°C DIP Package ........................... 1W
SOIC Package .....................................................................725mW
Storage Temperature Range ............................ -65°C to +150°C
Lead Temperature (Soldering, 10 seconds)........................ 300°C

Note 1: All voltages are with respect to Pin 5.
All currents are positive into the specified terminal.

The AIC3842 control IC provides the features that are necessary to implement off-line or DC/DC Converter fixed-frequency current-mode schemes with a minimum number of external components. AIC3842 integrated circuits features an undervoltage lockout (UVLO) with approximately 300mA start-up current, a precision reference trimmed for accuracy at the error amplifier input, high gain error amplifier, current sensing comparator, logic to insure latched operation, and a totem-pole output stage designed to source or sink high peak current. The output stage, suitable for driving N channel MOSFETs, is low in the off state.
