Features: 4V to 24V Input Voltage Operation. Adjustable Output Voltage. Low Quiescent Current at 100A. Pulse-Skipping and Pulse-Frequency ModulationMaintain High Efficiency (max. 95%). 90KHz to 250KHz Oscillator Frequency. Power-Saving Shutdown Mode (8A Typical). Push-Pull Driver Output.Applicati...
AIC1628: Features: 4V to 24V Input Voltage Operation. Adjustable Output Voltage. Low Quiescent Current at 100A. Pulse-Skipping and Pulse-Frequency ModulationMaintain High Efficiency (max. 95%). 90KHz to 250...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
The AIC1628 is a high performance step-up DC/DC converter, designed to drive an external power switch to generate programmable positive voltages. In the particularly suitable LCD contrast bias and flash memory programming power supply applications, typical full-load efficiencies are 85% to 95%. 4V to 24V input operation range allows the AIC1628 to be powered directly by the battery pack in the most batteryoperated applications for greater efficiency.Output voltage can be scaled to 40V or greater by two external resistors. A Pulse-Frequency Modulation scheme is employed to maintain high efficiency conversion under wide input voltage range. Quiescent current is about 100A and can be reduced to 8A in shutdown mode. Switching frequency being around 90KHz to 250KHz range, small size switching components are ideal for battery powered portable equipments, like notebook and palmtop computers.
