AD9883AKST-140

IC FLAT PANEL INTERFACE 80-LQFP

product image

AD9883AKST-140 Picture
SeekIC No. : 004273654 Detail

AD9883AKST-140: IC FLAT PANEL INTERFACE 80-LQFP

floor Price/Ceiling Price

Part Number:
AD9883AKST-140
Mfg:
Analog Devices Inc
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/13

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Pinout

  Connection Diagram


Description

The AD9883AKST-140 is a complete 8-bit, 140 MSPS, monolithic analog interface.Its advantage is capturing RGB grap hics signals from personal computers and workstations. Its 140 MSPS encode rate capability and full power analog bandwidth of 300 MHz supports resolutions can reach SXGA (1280 * 1024 at 75 Hz). The AD9883AKST-140 includes a 140 MHz triple ADC with internal 1.25 V reference, a PLL, and programmable gain, offset, and clamp control. The user offers only a 3.3 V power supply, analog input, and Hsync and COAST signals. Three-state CMOS outputs may be powered from 2.5 V to 3.3 V.

The AD9883AKST-140 has the following features:(1)industrial temperature range operation;(2)140 MSPS maximum conversion rate;(3)300 MHz analog bandwidth;(4):0.5 V to 1.0 V analog input range;(5):500 ps p-p PLL clock jitter at 110 MSPS;(6)3.3 V power supply;(7)full sync processing;(8)sync detect for hot plugging;(9)midscale clamping.etc.

AD9883AKST-140 also has some outstanding absolute maximum ratings and specifications.absolute maximum ratings:(1):VD is 3.6 V;(2):VDD is 3.6 V;(3)analog inputs is VD V to 0.0 V;(4):VREF IN is VD V to 0.0 V;(5):digital inputs is 5 V to 0.0 V(6): dig ital output current is 20 mA;(7):operating temperature is from40°C to +85°C;(8):storage temperature is65°C to +150°C;(9):maximum junction temperature is 150°C. specifications:(1):DC accurancy:differential nonlinearity is ±0.5 LSB typ;integral nonlinearity is ±0.5 LSB typ and±2.0 max;(2):analog input:gain tempco is 100 ppm/ typ,inp ut current bias is 1 uA max,input offset voltage is 7 mV min and 70 mV max;input full-scale matching is 1.5%FS typ and 8.0%FS;(3):reference output:output voltage is 1.2 V min,1.25 V typ and 1.32 V max,temperature coefficient is ±50ppm/°C typ;(4):digital input:input voltage, high (VIH) is 2.5 V min,input voltage, low (VIL) is 0.8 V min.




Parameters:

Technical/Catalog InformationAD9883AKST-140
VendorAnalog Devices Inc
CategoryIntegrated Circuits (ICs)
ApplicationsDisplays, Monitors, TV
InterfaceAnalog
Voltage - Supply3 V ~ 3.6 V
Package / Case80-LQFP
PackagingTube
RoHS StatusRoHS Non-Compliant
Other Names AD9883AKST 140
AD9883AKST140
