83C576

80C51 based architecture
8k * 8 ROM (83C576)
8k * 8 EPROM (87C576)
256 * 8 RAM
10-bit, 6 channel A/D
Three 16-bit counter/timers
2 PWM outputs
Programmable Counter Array
Universal Peripheral Interface
Enhanced UART
Oscillator fail detect
Low active reset
4 analog comparators
Watchdog timer
Low V_CC  detect
Power-on detect
Memory addressing capability
64k ROM and 64k RAM
Power control modes:
Idle mode
Power-down mode
CMOS and TTL compatible
6 to 16MHz
Extended temperature ranges

OTP available
That can be programmed in circuit
Software Reset
15 source, 2 level interrupt structure
Lower EMI noise
Programmable I/O pins

Serial on-board programming
Schmitt trigger inputs on Port 1

The Philips 83C576/87C576 is a high-performance microcontroller fabricated with Philips high-density CMOS technology. The Philips CMOS technology combines the high speed and density
characteristics of HMOS with the low power attributes of CMOS. Philips epitaxial substrate minimizes latch-up sensitivity.

The 8XC576 contains an 8k × 8 ROM (83C576) EPROM (87C576), a 256 × 8 RAM, 32 I/O lines, three 16-bit counter/timers, a Programmable Counter Array (PCA), a 10-bit, 6 channel A/D,2 PWM outputs, an 8-bit UPI interface, a fifteen-source, two-priority level nested interrupt structure, an enhanced UART, four analog comparators, power-fail detect and oscillator fail detect circuits, and clock circuits.

In addition, the 8XC576 has a low active reset, and a software reset. There is also a fully configurable watchdog timer, and internal power on clear circuit. The part includes idle mode and power-down mode states for reduced power consumption.
