80C52

Power control modes
256 bytes of RAM
8 Kbytes of ROM (80C52)
32 programmable I/O lines
Three 16 bit timer/counters
64 K program memory space
64 K data memory space
Fully static design
0.8 CMOS process
Boolean processor
6 interrupt sources
Programmable serial port
Temperature range : commercial, industrial, automotive military

TEMIC's 80C52 and 80C32 are high performance CMOS versions of the 8052/8032 NMOS single chip 8 bit C.The fully static design of the TEMIC 80C52/80C32 allows to reduce system power consumption by bringing the clock frequency down to any value, even DC, without loss of data.The 80C52 retains all the features of the 8052 : 8 K bytes of ROM ; 256 bytes of RAM ; 32 I/O lines ; three 16 bit timers ; a 6-source, 2-level interrupt structure ; a full
duplex serial port ; and on-chip oscillator and clock circuits. In addition, the 80C52 has 2 software-selectable
modes of reduced activity for further reduction in power consumption. In the idle mode the CPU is frozen while the RAM, the timers, the serial port and the interrupt system continue to function. In the power down mode the RAM is saved and all other functions are inoperative.The 80C32 is identical to the 80C52 except that it has no on-chip ROM. TEMIC's 80C52/80C32 are manufactured using SCMOS process which allows them to run from 0up to 44 MHz with Vcc = 5 V.EMIC's 80C52 and 80C32 are also available at 16 MHz with 2.7 V < V_CC < 5.5 V.
80C32 : Romless version of the
80C52 80C32/80C52-L16 : Low power version Vcc : 2.7 5.5 V Freq : 0-16 MHz
80C32/80C52-12 : 0 to 12 MHz
80C32/80C52-16 : 0 to 16 MHz
80C32/80C52-20 : 0 to 20 MHz
80C32/80C52-25 : 0 to 25 MHz
80C32/80C52-30 : 0 to 30 MHz
80C32/80C52-36 : 0 to 36 MHz
80C32-40 : 0 to 40 MHz*
80C32-42 : 0 to 42 MHz*
80C32-44 : 0 to 44 MHz*
* 0 to 70 temperature range.For other speed and temperature range availability please consult your sales office.
