74VHC16240

The 74VHC16240 is an advanced high-speed CMOS 16-BIT BUS BUFFER (3-STATE) fabricated with sub-micron silicon gate and double-layer metal wiring C²MOS technology.Any nG output control governs four BUS BUFFERS. Output Enable inputs (nG) tied together give full 16 bit operation.

When nG is LOW, the outputs are on. When nG is HIGH, the output are in high impedance state. This device is designed to be used with 3 state memory address drivers, etc.

Power down protection of the 74VHC16240 is provided on all inputs and outputs and 0 to 7V can be accepted on inputs with no regard to the supply voltage. This device can be used to interface 5V to 3V.

All inputs and outputs of the 74VHC16240 are equipped with protection circuits against static discharge, giving them 2KV ESD immunity and transient excess voltage.
