74HC126

Features: SpecificationsDescriptionThe 74HC126 is designed as high-speed si-gate CMOS devices and are pin compatible with low power schottky TTL (LSTTL). It is specified in compliance with JEDEC standard no. 7A which is four non-inverting buffer drivers with 3-state outputs. The 3-state outputs (n...

product image

74HC126 Picture
SeekIC No. : 004250689 Detail

74HC126: Features: SpecificationsDescriptionThe 74HC126 is designed as high-speed si-gate CMOS devices and are pin compatible with low power schottky TTL (LSTTL). It is specified in compliance with JEDEC sta...

floor Price/Ceiling Price

Part Number:
74HC126
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:






Specifications






Description

The 74HC126 is designed as high-speed si-gate CMOS devices and are pin compatible with low power schottky TTL (LSTTL). It is specified in compliance with JEDEC standard no. 7A which is four non-inverting buffer drivers with 3-state outputs. The 3-state outputs (nY) are controlled by the output enable input (nOE). A low at nOE causes the outputs to assume a high impedance off-state. It has two features which means its output capability would be bus driver and ICC category would be MSI.

Some important AC characteristics and specifications of the 74HC126 have been concluded into several points as follow.For Tamb=25°C the first one is about its propagation delay which would be typ 30ns and max 100ns at Vcc=2.0V and would be typ 11ns and max 20ns at Vcc=4.5V and would be typ 9ns and max 17ns at Vcc=6.0V. The second one is about its 3-state output enable time which would be typ 41ns and max 125ns at Vcc=2.0V and typ 15ns and max 25ns at Vcc=4.5V and would be typ 12ns and max 21ns at Vcc=6.0V. The third one is about its 3-state output disable time which would be typ 41ns and max 125ns at Vcc=2.0V and typ 15ns and max 25ns at Vcc=4.5V and would be typ 12ns and max 21ns at Vcc=6.0V. The fourth one is about its output transition time which would be typ 14ns and max 60ns at Vcc=2.0V and typ 5ns and max 12ns at Vcc=4.5V and would be typ 4ns and max 10ns at Vcc=6.0V.

Also for the Tamb range of -40 to +125°C the first one is about its propagation delay which would be max 150ns at Vcc=2.0V and would be max 30ns at Vcc=4.5V and would be max 26ns at Vcc=6.0V. The second one is about its 3-state output enable time which would be max 190ns at Vcc=2.0V and max 38ns at Vcc=4.5V and would be max 32ns at Vcc=6.0V. The third one is about its 3-state output disable time which would be max 190ns at Vcc=2.0V and max 38ns at Vcc=4.5V and would be max 32ns at Vcc=6.0V. The fourth one is about its output transition time which would be max 90ns at Vcc=2.0V and max 18ns at Vcc=4.5V and would be max 15ns at Vcc=6.0V. And so on. For more information please contact us.
