54LVTH245ARPFB

Maxwell Technologies' 54LVTH245ARPFB 8-bit octal transceiver micro-circuit features a greater than 100 krad (Si) total dose tolerance, depending upon space mission. The 54LVTH245ARPFB is designed specifically for low voltage (3.3V) VCC operation,but with the capability to provide a TTL interface to a 5V system environment. It is designed for asynchronous communication between data buses. The device transmits data from the A bus to the B bus or from the B bus to the A bus depending upon the logic level at the direction control (DIR) input. The output enable (OE) input of 54LVTH245ARPFB can be used to disable the device so the buses are effectively isolated. The 54LVTH245A active bus-hold circuitry is provided to prevent floating data inputs at a valid logic level and to eliminate the need for external pullup resistors.

Maxwell Technologies' patented RAD-PAK® packaging technology of 54LVTH245ARPFB incorporates radiation shielding in the microcircuit package.It eliminates the need for box shielding while providing the required radiation shielding for a lifetime in orbit or space mission. In a GEO orbit, RAD-PAK provides greater than 100 krad (Si) radiation dose tolerance. This 54LVTH245ARPFB is available with screening up to Class S.
