28F032C3

Flexible SmartVoltage Technology
 -2.7 V3.6 V Read/Program/Erase
 -2.7 V or 1.65 V I/O Option Reduces Overall System Power
 -12 V for Fast Production Programming
High Performance
 -2.7 V3.6 V: 90 ns Max Access Time
 -3.0 V3.6 V: 80 ns Max Access Time
Optimized Architecture for Code Plus Data Storage
    -Eight 8-Kbyte Blocks,Top or Bottom Locations
 -Up to Sixty-Three 64-KB Blocks
 -Fast Program Suspend Capability
 -Fast Erase Suspend Capability
Flexible Block Locking
- Lock/Unlock Any Block
-Full Protection on Power-Up
-WP# Pin for Hardware Block Protection
-V_PP = GND Option
-V_CC Lockout Voltage
Low Power Consumption
 -9 mA Typical Read Power
 -10 µA Typical Standby Power with Automatic Power Savings Feature
Extended Temperature Operation
 -40 °C to +85 °C
Easy-12 V
 -Faster Production Programming
 -No Additional System Logic
128-bit Protection Register
 -64-bit Unique Device Identifier
 -64-bit User Programmable OTP Cells
Extended Cycling Capability
  -Minimum 100,000 Block Erase Cycles
Flash Data Integrator Software
  -Flash Memory Manager
  -System Interrupt Manager
  -Supports Parameter Storage,Streaming Data (e.g., voice)
Automated Word/Byte Program and Block Erase
 -Command User Interface
 -Status Registers
SRAM-Compatible Write Interface
Cross-Compatible Command Support
- Intel Basic Command Set
-Common Flash Interface
x 16 for High Performance
 -48-Ball µBGA* Package
 -48-Lead TSOP Package
x 8 I/O for Space Savings
 -48-Ball µBGA* Package
 -40-Lead TSOP Package
0.25 µ ETOX™ VI Flash Technology
