EEE-FP1C100AR, EEE-FP1C101AP, EEE-FP1C220AR

Table of contents:
Info of EEE-FP1C100AR
Info of EEE-FP1C101AP
Info of EEE-FP1C220AR

EEE-FP1C100AR, EEE-FP1C101AP, EEE-FP1C220AR Selling Leads, Datasheet

MFG:Panasonic - ECG (VA) Category:Capacitors Package Cooled:SMD D/C:09+

EEE-FP1C100AR, EEE-FP1C101AP, EEE-FP1C220AR Datasheet download

Five Points

Part Number: EEE-FP1C100AR

Category: Capacitors

MFG: Panasonic - ECG (VA)

Package Cooled: SMD

D/C: 09+

Description: CAP 22UF 16V ELECT FP SMD

Price Break

5
10
25
100
500

Unit Price

.26600
.22000
.20400
.18840
.15700

Extended Price

1.33
2.20
5.10
18.84
78.50

(All prices are in USD) Prices for reference only

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

EEE-FP1C100AR Parameters

Technical/Catalog Information	EEE-FP1C100AR
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	10F
ESR (Equivalent Series Resistance)	850.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.158" Dia x 0.228" H (4.00mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.169" L x 0.169" W (4.30mm x 4.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1C100AR EEEFP1C100AR PCE4527DKR ND PCE4527DKRND PCE4527DKR

EEE-FP1C101AP Parameters

Technical/Catalog Information	EEE-FP1C101AP
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	100F
ESR (Equivalent Series Resistance)	260.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.248" Dia x 0.228" H (6.30mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.260" L x 0.260" W (6.60mm x 6.60mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Cut Tape (CT)
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1C101AP EEEFP1C101AP PCE4533CT ND PCE4533CTND PCE4533CT

EEE-FP1C220AR Parameters

Technical/Catalog Information	EEE-FP1C220AR
Vendor	Panasonic - ECG (VA)
Category	Capacitors
Capacitance	22F
ESR (Equivalent Series Resistance)	360.0 mOhm
Features	General Purpose
Lifetime @ Temp.	2000 Hrs @ 105°C
Maximum Temperature	-55°C ~ 105°C
Size / Dimension	0.197" Dia x 0.228" H (5.00mm x 5.80mm)
Lead Spacing	-
Surface Mount Land Size	0.209" L x 0.209" W (5.30mm x 5.30mm)
Mounting Type	Surface Mount
Package / Case	Radial - Surface Mount
Packaging	Digi-Reel?
Tolerance	±20%
Voltage Rating	16V
Lead Free Status	Lead Free
RoHS Status	RoHS Compliant
Other Names	EEE FP1C220AR EEEFP1C220AR PCE4528DKR ND PCE4528DKRND PCE4528DKR
