AS1341CS, AS1357, AS1357-F0F-T

Table of contents:
Info of AS1341CS
Info of AS1357
Info of AS1357-F0F-T

AS1341CS, AS1357, AS1357-F0F-T Selling Leads, Datasheet

MFG:AMS Package Cooled:6000 D/C:2007+

AS1341CS, AS1357, AS1357-F0F-T Datasheet download

Five Points

Part Number: AS1341CS

MFG: AMS

Package Cooled: 6000

D/C: 2007+

Attentive hint

Want to post a buying lead? If you are not a member yet, please select the specific/related part number first and then fill the quantity and your contact details in the "Request for Quotation Form" on the left, and then click "Send RFQ".Your buying lead can then be posted, and the reliable suppliers will quote via our online message system or other channels soon.

How to buy ?

How long will receive a response.

Top Sellers:

TOP

AS1357 General Description

The AS1357 is a high-performance triple CMOS lowdropout voltage regulator in a single 3x3mm and 4x4mm QFN package. The efficient set of programmable power supplies is optimized to deliver the best compromise between quiescent current and regulator performance for mobile phones, PDAs, MP3 players, and other battery powered devices.

The one-time-programmable (OTP) function provides greater design flexibility by allowing for independent programming of the output voltage for each regulator onsite. The OTP function allows for fast prototyping as well as full-production in the field. Factory trimmed versions are also available.

Stability is guaranteed with ceramic output capacitors of only 1F (±20% . X5R) up to 4.7F (±20% . X5R). The low equivalent series resistance (ESR) of these capacitors ensures low output impedance at high frequencies.

Regulation performance is excellent even under low dropout conditions, when the power transistor has to operate in linear mode.

The low-noise performance allows direct connection of noise sensitive circuits without additional filtering networks.

The AS1357 is available in a 16-pin QFN 3x3 package and in a 12-pin QFN 4x4 package.

AS1357 Connection Diagram
