Maxwell Technologies' 8408 is a monolithic quad 8-bit multi-plying digital-to-analog CMOS converter. Each DAC has its own reference input, feedback resistor, and onboard data latches that feature read/write capability. The readback func- tion serves as memory for those systems requiring self-diag-nostics.
A common 8-bit TTL/CMOS compatible input port is used to load data into any of the four DAC data-latches. Control lines DS1, DS2 and A/B determine which DAC will accept data. Data loading is similar to that of a RAMs write cycle. Data can be read back onto the same bus with control line R/W. The 8408 is a bus compatible with most 8-bit microprocessors,including the 6800, 8080, 8085, and Z80. The 8408 operates on a single +5 volt supply and dissipates less than 20 mW.The 8408 is manufactured using highly stable, thin-film resistors on an advanced oxide-isolated, silicon-gate, CMOS process. The improved latch-up resistant design eliminates the need for external protective Schottky diodes.
Maxwell Technologies' patented RAD-PAK(R) packaging technology incorporates radiation shielding in the microcircuit pack-age. It eliminates the need for box shielding while providing the required radiation shielding for a lifetime in orbit or space mission. In a GEO orbit, RAD-PAK provides greater than 100krad (Si) radiation dose tolerance. This product is available with screening up to Class S.
8408 Maximum Ratings
PARAMETER
SYMBOL
MIN
MAX
UNIT
VDD to I OUT 2A , I OUT 2B, I OUT 2C, I OUT 2D
--
0
7
V
V DD to DGND
--
0
7
V
I OUT 1A, I OUT 1B, I OUT 1C, I OUT 1D to DGND
--
-0.3
VDD + 0.3
V
R RFA, RRF B, VRFC, RRFD to IOUT
--
-0.3
±25
V
I OUT 2A,I OUT 2B, I OUT 2C,I OUT 2D to DGND
--
-0.3
VDD + 0.3
V
DB0 through DB7 to DGND
--
-0.3
VDD + 0.3
V
Control Logic Input Voltage to DGND
--
VDD + 0.3
V
VREF A, VREF B, V REFC, V REFD to IOUT 2A,I OUT 2B, I OUT 2C,I OUT 2D
±25
Power Dissipation
PD
mW
Operating Temperature
TA
-55
20
Storage Temperature Range
TS
-65
125
8408 Features
*RAD-PAK(R) patented shielding against natural * space radiation * Total dose hardness: - equal to 100 krad (Si), depending upon orbit and space mission * Package: - 28 pin RAD-PAK(R) Flat Pack * Single Supply Ooperation (+5V) * Four 8 Bit DACs in one 28 Pin Package * D/As Matched to within 1% * TTL/CMOS Compatable * Four-Quadrant Multiplication
