Product Details

Description

Features:

` 2.4GHz RF transmitter
` 8051 compatible micro-controller
` compatible with nRF24E1
` 9 input 10 bit ADC 100kSPS
` Single 1.9V to 3.6V supply
` Internal voltage regulators
` 2 A standby with wakeup on timer or external pin
` Internal VDD monitoring
` Supplied in 36 pin QFN (6x6mm) package
` 0.18m CMOS technology
` Low Bill- of Material
` Ease of design
` Wireless gamepads
` Wireless headsets
` Wireless keyboards
` Wireless mouse
` Wireless toys
` Intelligent sports equipment
` Industrial sensors
` PC peripherals
` Phone peripherals
` Tags
` Alarms
` Remote control

Pinout

Connection Diagram

Description

The nRF24E2 is the transmitter part of the nRF2401 2.4GHz radio transceiver plus an embedded 8051 compatible microcontroller plus a 10-bit 9 input 100 kSPS AD converter. The circuit is supplied by only one voltage in range 1.9V to 3.6V. The nRF24E2 supports the proprietary and innovative modes of the nRF2401 such as ShockBurst™.nRF24E2 is also a subset of the nRF24E1 chip, which means that it contains all functions of nRF24E1 except the radio receive functions, and it also means that it is fully program compatible with nRF24E1.
