ZXFV202

Features: • -3dB bandwidth 300MHz• Slew rate 400V/µs• Differential gain 0.01%• Differential phase 0.01°• Output current 40mA• Characterised up to 400pF load• ±5 Volt supply• Supply current 7mA• SOT23-5 packageApplication• Video gain...

product image

ZXFV202 Picture
See larger image
SeekIC No. : 004552385 Detail

ZXFV202: Features: • -3dB bandwidth 300MHz• Slew rate 400V/µs• Differential gain 0.01%• Differential phase 0.01°• Output current 40mA• Characterised up to 400pF load...

ZXFV202 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
ZXFV202
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2024/11/23

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

• -3dB bandwidth 300MHz
• Slew rate 400V/µs
• Differential gain 0.01%
• Differential phase 0.01°
• Output current 40mA
• Characterised up to 400pF load
• ±5 Volt supply
• Supply current 7mA
• SOT23-5 package




Application

• Video gain stages
• CCTV buffer
• Video distribution
• RGB buffering
• High frequency instrumentation
• Cable Driving
• Radar Imaging
• Medical Imaging




Pinout

Connection Diagram




Specifications

Supply Voltage. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . . . . . . .. . .. . .. . .. . .. . .. ±5.25V
Inputs to ground
Outputs to ground
Operating Temperature Range. .. . .. . .. . .. . .. . .. ..-40°C to 85°C Storage -65°C to 150°C
Continuous Power Dissipation. . . . . . . . . . . . . . . . .. . . . . . . . . . . . .. . .. . .. . .. . .. . .. . 250mW
Thermal resistance. . . . . . . . . . . . . . . . .. . . . . . . . . . . . . . . . .. . .. . .. . .. . .. . .. . .. . 250°C/W
The power dissipation of the device including the loads must be designed to keep tj below 150°C




Description

The ZXFV202 is a single high speed amplifier designed for video and other high speed applications. Packaged in a small SOT23-5 it is ideally suited to applications where space is at a premium. In applications where cross talk is critical this part provides better isolation than dual or quad devices.

ZXFV202 features low differential gain and phase performance. High output drive capability compliments this part for use in video applications.
