ZL40121

Note 1: Absolute Maximum Ratings indicate limits beyond which damage to the device may occur. Operating Ratings indicate conditions for which the device is intended to be functional, but specific performance is not guaranteed. For guaranteed specifications and the test conditions, see the Electrical Characteristics.
Note 2: Human body model, 1.5k in series with 100pF. Machine model, 20in series with 100pF.
Note 3: 0.8kV between the pairs of +INA, -INA and +INB pins only. 2kV between supply pins, OUTA or OUTB pins and  ny input pin.
Note 4: ±100mA applied to input and output pins to force the device to go into "latch-up". The device passes this test  o JEDEC spec 17.
Note 5: Positive and Negative supply transient testing increases the supplies by 20% for 100ms.

The ZL40121 is a low power, dual, current feedback operational amplifier offering high performance at a low cost. The device provides a very high output current drive capability of 65mA while requiring only 3.3mA of static supply current per channel. This feature makes the ZL40121 the ideal choice where a high density of high speed devices is required.

The 280MHz Av=+1V/V small signal bandwidth and 1100V/s slew rate make the device an excellent solution for component video applications such as driving RGB signals down significant cable lengths.

Other applications which may take advantage of the ZL40121 dynamic performance features and matched amplifiers include low cost high order active filters and twisted pair driver/receivers.
