Parameter |
Value |
Supply Voltage Voltage on other input pins Temperature under bias Storage Temperature Maximum DC TTL output Current Magnitude |
-0.5 to +7.0 volts -0.5 to VDD + 0.5 volts -15 to 85 -30 to 125 10mA (per o/p, one at a time, 1sec. duration) |
The VV5402 is a highly-integrated VLSI camera device based on VISION's unique CMOS sensor technology. VV5402 is suitable for applications requiring a composite video output with minimum external circuitry. The device incorporates a 388 x 295 pixel image sensor and all the necessary support circuits to generate fully formatted composite video into a 75W load.
Automatic control of exposure, gain and black level allow use of a single fixed-aperture lens over a wide range of operating conditions. Normal and Backlit modes of VV5402 further enhance difficult scene types.
All major control functions are pin selectable giving maximum flexibility with ease of use. The VV5402 offers a complete camera system with only a few external components.
