VT98001

24.576 MHz for Firewire IEEE1394 or video digitizer
24.576 MHz / 28.224 MHz for software or hardware modem
27 MHz buffered output clock
6.000MHz buffered output clock
18.432 MHz for audio processor
2kHz standby clock
Zero ppm synthesis error in all clocks (except the 2 kHz standby clock)
5V tolerant inputs
20-pin, 150 mil SSOP (QSOP)

The Vaishali VT98001 is a single-chip, integrated multiple Phase Locked Loop (PLL) clock synthesizer. The device uses an analog Phase Locked Loop (PLL) to accept a 27 MHz crystal input to produce multiple outputs. Selection pins are used to provide various outputs.
