VSC7959

Power Supply Voltage (V_CC).......................... -0.5V to +6V
Maximum Junction Temperature Range .......................TBD
Storage Temperature Range (T_S)............ -55  to +150

NOTE: (1) CAUTION: Stresses listed under "Absolute Maximum Ratings" may be applied to devices one at a
                time without causing permanent damage. Functionality at or above the values listed is not
                implied.  Exposure to these values for extended periods may affect device reliability.

The VSC7959 is a single supply limiting amplifier with Loss of Signal (LOS) detect for SONET/SDH and Fibre Channel applications up to 3.125Gb/s. The VSC7959 provides a constant output signal swing for a wide range of input voltages and has Current-Mode Logic (CML) outputs. The VSC7961 provides the same functionality as the VSC7959 with positive emitter-coupled logic (PECL) outputs. Key features of the VSC7959 are its RMS power detectors for programmable LOS detection, optional output squelch, adjustable output levels, excellent jitter performance, and fast edge rates. The VSC7959 is available in die form or in a TSSOP-16 package.
