Features: 128Kx8-bit OrganizationAddress Access Time: 45, 70, 90 nsSingle 5V± 10% Power SupplySector Erase Mode Operation8KB Boot Block (lockable)512 bytes per Sector, 256 Sectors Sector-Erase Cycle Time: 10ms (Max) Byte-Program Cycle Time: 20s (Max)Minimum 10,000 Erase-Program CyclesLow power d...
V29C51001B: Features: 128Kx8-bit OrganizationAddress Access Time: 45, 70, 90 nsSingle 5V± 10% Power SupplySector Erase Mode Operation8KB Boot Block (lockable)512 bytes per Sector, 256 Sectors Sector-Erase Cycl...
SeekIC Buyer Protection PLUS - newly updated for 2013!
268 Transactions
All payment methods are secure and covered by SeekIC Buyer Protection PLUS.
Features: 512Kx8-bit OrganizationAddress Access Time: 90, 120 nsSingle 3.3V± 0.3 Power SupplySecto...
Features: 512Kx8-bit OrganizationAddress Access Time: 90, 120 nsSingle 3.3V± 0.3 Power SupplySecto...
Features: 64Kx8-bit OrganizationAddress Access Time: 45, 70, 90 nsSingle 5V± 10% Power SupplySecto...
Symbol |
Parameter |
Commercial |
Unit |
VIN |
Input Voltage (input or I/O pins) |
-2 to +7 |
V |
VIN |
Input Voltage (A9 pin, OE) |
-2 to +13 |
V |
VCC |
Power Supply Voltage |
-0.5 to +5.5 |
V |
TSTG |
Storage Temerpature (Plastic) |
-65 to +125 |
°C |
TOPR |
Operating Temperature |
0 to +70 |
°C |
IOUT |
Short Circuit Current(2) |
200 (Max.) |
mA |
The V29C51001T/V29C51001B is a high speed 131,072 x 8 bit CMOS flash memory. Programming or erasing the device is done with a single 5 Volt power supply. The device has separate chip enable CE, program enable WE, and output enable OE controls to eliminate bus contention.
The V29C51001T/V29C51001B offers a combination of features: Boot Block with Sector Erase Mode. The end of program/erase cycle is detected by DATA Polling of I/O7 or by the Toggle Bit I/O6.
The V29C51001T/V29C51001B features a sector erase operation which allows each sector to be erased and reprogrammed without affecting data stored in other sectors. The device also supports full chip erase.
Boot block architecture enables the device to boot from a protected sector loaded either at the top (V29C51001T) or the bottom (V29C51001B) sector. All inputs and outputs are CMOS and TTL compatible.
The V29C51001T/V29C51001B is ideal for applications that require updatable code and data storage.
