TSL260

Supply voltage, VDD (see Note 1)  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  10 V
Output current, IO . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .±10 mA
Duration of short-circuit current at (or below) 25°C (see Note 2) . . . . . . . . . . .  5 s
Operating free-air temperature range, TA . . . . . . . . . . . . . . . . . . . 25°C to 85°C
Storage temperature range  . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  25°C to 85°C
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds . . . . . . . . .  240°C
NOTES:
1. All voltages are with respect to GND.
2. Output may be shorted to either supply.

The TSL260, TSL261, and TSL262 are light-to-voltage optical sensors, each combining a photodiode and a transimpedance amplifier (feedback resistor = 16 MW, 8 MW, and 2 MW, respectively) on a single monolithic integrated circuit. The output voltage is directly proportional to the infrared light intensity (irradiance) on the photodiode. The TSL260, TSL261, and TSL262 are manufactured using advanced linear CMOS silicon-gate technology, which provides good amplifier offset-voltage stability and low power consumption.
