TSL218

Supply voltage range, V_DD  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  . . .0.5 V to 7 V
Digital output voltage range, V_O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .  .0.5 V to V_DD + 0.5 V
Digital output current, I_O . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3 mA
Digital input current range, I_I   . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20 mA to20 mA
Operating free-air temperature range, T_A  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .0°C to 70°C
Storage temperature range, T_stg  . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .. . .25°C to 85°C
Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .260°C

The TSL218 intelligent optosensor consists of eight sections of 64 charge-mode pixels arranged in a 512 * 1 linear array. Each pixel measures 120 m * 70 mm with 125-m center-to-center spacing. Operation is simplified by internal logic requiring only clock and serial-input pulse signals.

The TSL218 is intended for use in a wide variety of applications including contact imaging, barcode reading, edge detection and positioning, level detection, and linear encoding.
