TS27L4C

These devices of the TS27L4Care low cost, low power quad operational amplifiers designed to operate with single or dual supplies. These operational amplifiers use the ST silicon gate CMOS process allowing an excellent consumption-speed ratio. These series are ideally suited for low consumption applications.

Three power consumptions are available allowing to have always the best consumption-speed ratio:` I<sub>CC</sub> = 10A/amp.: TS27L4 (very low power)` I_CC = 150A/amp.: TS27M4 (low power)` I_CC = 1mA/amp.: TS274 (standard)
These CMOS amplifiers offer very high input impedance and extremely low input currents. The major advantage versus JFET devices is the very low input currents drift with temperature (see figure 2)
