TPA3002D2

·9-W/Ch Into an 8-Ω Load From 12-V Supply
·Efficient, Class-D Operation Eliminates Heatsinks and Reduces Power Supply Requirements
·32-Step DC Volume Control From −40 dB to 36 dB
·Line Outputs For External Headphone Amplifier With Volume Control
·Regulated 5-V Supply Output for Powering TPA6110A2
·Space-Saving, Thermally-Enhanced PowerPAD™Packaging
·Thermal and Short-Circuit Protection

The TPA3002D2 is a 9-W (per channel) efficient, Class-D audio amplifier for driving bridged-tied stereo speakers. The TPA3002D2 can drive stereo speakers as low as 8 Ω. The high efficiency of the TPA3002D2 eliminates the need for external heatsinks when playing music.Stereo speaker volume is controlled with a dc voltage applied to the volume control terminal offering a range of gain from 40 dB to 36 dB. Line outputs, for driving external headphone amplifier inputs, are also dc voltage controlled with a range of gain from 56 dB to 20 dB.An integrated 5-V regulated supply is provided for powering an external headphone amplifier.
