TP112

Supply Voltage ....................... V_CC 0.25 to V_DD +0.25V
Storage Temperature .................................-65 to 150°C
Ambient Operating Temperature (Ta)...............0 to 70°C
Stresses above those listed under Absolute Maximum Ratings may cause permanent damage to the device. Functional operation under these conditions is not impli d. Exposure to Absolute Maximum Rating conditions for extended periods may affect product reliability.

The TP112 is a single chip media converter for 100Base-TX to 100Base-FX. The TP112 support one 100Base-TX port over CAT5 twisted pair cable and oneECL interface to connect with fiber module to apply in  100Base-TX/FX converter application. On the 100Base-TX side, The TP112 is directly connected to external transformers

The chip performs data recovery, clock recovery,adaptive equalization, auto negotiation, and baseline  wander correction function. The TP112 is compliant with the IEEE 802.3u standard.
