TEA5767HL

· High sensitivity due to integrated low-noise RF input amplifier
· FM mixer for conversion to IF of the US/Europe (87.5 to 108 MHz) and Japanese (76 to 91MHz) FM band
· Preset tuning to receive Japanese TV audio up to 108 MHz
· RF Automatic Gain Control (AGC) circuit
· LC tuner oscillator operating with low cost fixed chip inductors
· FM IF selectivity performed internally
· No external discriminator needed due to fully integrated FM demodulator
· Crystal reference frequency oscillator; the oscillator operates with a 32.768 kHz clock crystal or with a 13 MHz crystal and with an externally applied 6.5 MHz reference frequency
· PLL synthesizer tuning system
· 3-wire bus
· 7-bit IF counter output via the 3-wire bus
· 4-bit level information output via the 3-wire bus
· Soft mute
· Signal dependent mono to stereo blend [Stereo Noise Cancelling (SNC)]
· Signal dependent High Cut Control (HCC)
· Soft mute, SNC and HCC can be switched off via the 3-wire bus
· Adjustment-free stereo decoder
· Autonomous search tuning function
· Standby mode
· Two software programmable ports
· Bus enable line to switch the bus input and output lines into 3-state mode
· Automotive temperature range (at V_CCA, V_CC(VCO) and V_CCD = 5 V).

The TEA5767HL is a single-chip electronically tuned FM stereo radio for low-voltage application with fully integrated IF selectivity and demodulation. The radio is completely adjustment-free and only requires a minimum of small and low cost external components. The radio can be tuned to the European, US and Japanese FM bands.
