TDF8704

Features: ` 8-bit resolution` Sampling rate up to 50 MHz` Extended temperature range (-40 to +85 )` High signal-to-noise ratio over a large analog input frequency range (7.4 effective bits at 4.43 MHz full-scale input and at fclk = 50 MHz)` Binary 3-state TTL outputs` Overflow/underflow 3-state TT...

product image

TDF8704 Picture
See larger image
SeekIC No. : 004517068 Detail

TDF8704: Features: ` 8-bit resolution` Sampling rate up to 50 MHz` Extended temperature range (-40 to +85 )` High signal-to-noise ratio over a large analog input frequency range (7.4 effective bits at 4.43 M...

TDF8704 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
TDF8704
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

` 8-bit resolution
` Sampling rate up to 50 MHz
` Extended temperature range (-40 to +85 )
` High signal-to-noise ratio over a large analog input frequency range (7.4 effective bits at 4.43 MHz full-scale input and at fclk = 50 MHz)
` Binary 3-state TTL outputs
` Overflow/underflow 3-state TTL output
` TTL compatible digital inputs
` Low-level AC clock input signal allowed
` Stable internal reference voltage regulator included
` Power dissipation only 380 mW (typical)
` Low analog input capacitance, no buffer amplifier required
` No sample-and-hold circuit required.


Application

· General purpose high-speed analog-to-digital conversion for extended temperature applications
· Automotive
· RF, satellite and GPS (Global Positioning System)
· Medical
· General industrial
· Digital video (VCR, TV and satellite).


Pinout

Connection Diagram


Description

The TDF8704T is an 8-bit high-speed analog-to-digital converter (ADC) for general industrial applications. It converts the analog input signal into 8-bit binary-coded digital words at a maximum sampling rate of 50 MHz. All digital inputs and outputs are TTL compatible, although a low-level AC clock input signal is allowed.
