TDA9874H

SIF input switch e.g. to select between terrestrial TV SIF and SAT SIF sources
SIF AGC with 21dB control range
SIF 8-bit Analog-to-Digital Converter (ADC)
DQPSK demodulation for different standards,
simultaneously with 1-channel FM demodulation
NICAM decoding (B/G, I and Lstandard)
Two-carrier multi-standard FM demodulation
B/G, D/K and Mstandard)
Decoding for three analog multi-channel systems
A2, A2+ and A2*) and satellite sound
Adaptive de-emphasis for satellite
Programmable identification (B/G, D/K and Mstandard)
and different identification times
Optional AM demodulation for systemL, simultaneously with NICAM
Monitor selection for FM/AM demodulator outputs and
FM and NICAM signals
Digital crossbar switch
I²S serial audio output with matrix, level adjust and mute
Dual audio Digital-to-Analog Converter (DAC) from
digital crossbar switch to analog crossbar switch,bandwidth 15kHz
Analog crossbar switch with inputs for mono and stereo
Output selection of mono, stereo, dual, dual A or dual B
20kHz bandwidth for analog path Standby mode.

   The TDA9874H is a single-chip Digital TV Sound Demodulator/Decoder (DTVSD1) for analog and digital multi-channel sound systems in TV/VCR sets and satellite receivers.
