TDA9801

Features: Suitable for negative vision modulationApplicable for IF frequencies of 38.9, 45.75 and 58.75MHzGain controlled wide-band Vision IntermediateFrequency (VIF) amplifier (AC-coupled)True synchronous demodulation with active carrierregeneration (ultra-linear demodulation, goodintermodulation...

product image

TDA9801 Picture
See larger image
SeekIC No. : 004516949 Detail

TDA9801: Features: Suitable for negative vision modulationApplicable for IF frequencies of 38.9, 45.75 and 58.75MHzGain controlled wide-band Vision IntermediateFrequency (VIF) amplifier (AC-coupled)True sync...

TDA9801 Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
TDA9801
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Suitable for negative vision modulation
Applicable for IF frequencies of 38.9, 45.75 and 58.75MHz
Gain controlled wide-band Vision Intermediate
Frequency (VIF) amplifier (AC-coupled)
True synchronous demodulation with active carrier
regeneration (ultra-linear demodulation, good
intermodulation figures, reduced harmonics and
excellent pulse response)
Peak sync pulse AGC
Video amplifier to match sound trap and sound filter
AGC output voltage for tuner with fixed resistor for takeover point setting
AFC detector without extra reference circuit
Alignment-free FM-PLL detector with high linearity


Pinout

Connection Diagram


Specifications

SYMBOL PARAMETER MIN. MAX UNIT
VP supply voltage (pin 6) 0 10 V
Vn voltage on all pins, ground excluded 0 VP V
IO output current
at pins 15, 18, 13, 20, 7 and 26
at pins 2 and 31		 -
-		 2.5
1.5		 mA
mA
Ptot total power dissipation - 850 mW
Tstg storage temperature -25 +150 °C
Tamb operating ambient temperature -20 +70 °C
VESD electrostatic handling for all pins (note 1) -300 +300 V



Description

The TDA9801(T)is a monolithic integrate dcircuit for vision and sound IF signal processing in TV and VTR sets and
multimedia front-ends.
