TDA7503

·Dual 24-bit 40 MIPS DSP Cores
·8 bit Microcontroller
·4 receive and 5 transmit stereo channels of Serial Audio Interface
·Synchronous Serial Interface for communication with external processor
·FIFO based mailboxes for inter-processor communications
·External Memory Interface to 128Kb SRAM or 1Mb DRAM
·CORDIC co-processor
·Programmable PLL to suite wide range of external crystal oscillation frequencies
·SPI control interface
·Powerful debug interfaces
·1280 words Program Memory for DSP1, 768 words Program Memory for DSP0
·256 words X and Y Data RAM and Data ROM for each DSP
·256 byte Data RAM for Microcontroller
·768 byte Auxiliary RAM for Microcontroller

The TDA7503 is a high-performance Digital Signal Processing IC particularly suited to Audio applications. The device contains two 24-bit 40 MIPS DSP cores delivering a total of 80 MIPS of DSP processing power. There is also an embedded 8- bit Microcontroller to handle all control functions. All data and program memories for both DSP cores are on-chip. A variety of highly programmable and flexible peripheral blocks for both the Microcontroller and the DSPs have been integrated to form a powerful audio processing system on a single chip.
