TDA7478

VERY HIGH RDS DEMODULATION QUALITY
    WITH IMPROVED DIGITAL SIGNAL
    PROCESSING
HIGH PERFORMANCE, 57KHz BANDPASS
    FILTER (8th ORDER)
FILTER ADJUSTMENT FREE AND WITHOUT
    EXTERNAL COMPONENTS
PURELY DIGITAL RDS DEMODULATION
    WITHOUT EXTERNAL COMPONENTS
RDS SIGNAL QUALITY OUTPUT
4.332MHz CRYSTAL OSCILLATOR(8.664MHz
    OPTIONAL)
LOW NOISE CMOS TECHNOLOGY
LOW RADIATION

The TDA7478 recovers the additional inaudible RDS information which is transmitted by FM radio broad- casting stations and operates in accordance with theEBU (European Broadcasting Union) specifications.

The TDA7478 is made up of two sections: a cascaded antialiasing + switched capacitors 8^th  bandpass filter for precise RDS band selection and a demodulating section that performs the extraction od RDS data stream (RDDA) and clock (RDCL), to be further pro- cessed by a suitable RDS decoder.

Output for RDS signal quality of the TDA7478 is also present.
