TC9457F

Features: CMOS−technology DTS microcontroller LSI incorporating a CD digital servo and LCD/LED driverOperating supply voltage:When CD is operating, VDD = 4.5 to 5.5 V (5.0 V typ.)When CD is turned off, VDD = 2.7 to 5.5 V (CPU operating)Current consumption:When CD is operating, IDD = 55 mA (t...

product image

TC9457F Picture
See larger image
SeekIC No. : 004515314 Detail

TC9457F: Features: CMOS−technology DTS microcontroller LSI incorporating a CD digital servo and LCD/LED driverOperating supply voltage:When CD is operating, VDD = 4.5 to 5.5 V (5.0 V typ.)When CD is tu...

TC9457F Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
TC9457F
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

CMOS−technology DTS microcontroller LSI incorporating a CD digital servo and LCD/LED driver
Operating supply voltage:
When CD is operating, VDD = 4.5 to 5.5 V (5.0 V typ.)
When CD is turned off, VDD = 2.7 to 5.5 V (CPU operating)
Current consumption:
When CD is operating, IDD = 55 mA (typ.)
When CD is turned off, IDD = 2 mA (typ.) (using 4.5 MHz crystal; CPU operating)
When CD is turned off, IDD = 0.1 mA (using 75 kHz crystal; CPU operating)
Operating temperature range: Ta = −40 to 85 °C
Firmware


Pinout

Connection Diagram


Description

The TC9457F is a firmware incorporating CD digital servo system. In addition to an LCD/LED driver, 4-channel 6-bit AD converters, and 2-wire/3-wire serial interface, it has a buzzerfunction, interrupt function, and 8-bit timer/counter. The TC9457F CPU allows selection of the operating clock from three types of crystaloscillators (16.9344 MHz, 4.5 MHz, and 75 kHz), making interfacing with a CD easy. The CD digital servo incorporatesvarious functions and circuits required for CD systems. These include sync separation protection and interpolation, EFM demodulation, error correction, digital equalizer for servoing, a servo control circuit. Furthermore, it contains a 1-bit DA converter, so that when combined with the digital servo head amp TA2109F, TC9457F allows you to create a maintenance-free, extremely simple CD player system.
