TC90A67F

Features: Video Decoder for the Sub-PictureNTSC, PAL (Europe), M-PAL and N-PAL systemsAutomatic color system identification8-bit ADC for a composite video inputY/C separation by built-in digital filtersACC, Color killer circuitsContrast, Brightness, Tint and Color level controls Accessible V-chip ...

product image

TC90A67F Picture
See larger image
SeekIC No. : 004515202 Detail

TC90A67F: Features: Video Decoder for the Sub-PictureNTSC, PAL (Europe), M-PAL and N-PAL systemsAutomatic color system identification8-bit ADC for a composite video inputY/C separation by built-in digital fil...

TC90A67F Data Sheet

floor Price/Ceiling Price

Get Latest Price
Part Number:
TC90A67F
Supply Ability:
5000

Price Break

  • Qty
  • 1~5000
  • Unit Price
  • Negotiable
  • Processing time
  • 15 Days
Total Cost: $ 0.00

SeekIC Buyer Protection PLUS - newly updated for 2013!

  • Escrow Protection.
  • Guaranteed refunds.
  • Secure payments.
  • Learn more >>

Month Sales

268 Transactions

Rating

evaluate  (4.8 stars)

Upload time: 2025/1/12

add to my favourite

Payment Methods

All payment methods are secure and covered by SeekIC Buyer Protection PLUS.

Notice: When you place an order, your payment is made to SeekIC and not to your seller. SeekIC only pays the seller after confirming you have received your order. We will also never share your payment details with your seller.
Product Details

Description



Features:

Video Decoder for the Sub-Picture
NTSC, PAL (Europe), M-PAL and N-PAL systems
Automatic color system identification
8-bit ADC for a composite video input
Y/C separation by built-in digital filters
ACC, Color killer circuits
Contrast, Brightness, Tint and Color level controls
Accessible V-chip signal data via. IIC bus
Main-Picture System Clock
External PLL circuit for main-picture system clock (A recommended IC TI: TLC2933)
PIP Controller
525-60 Hz, 626-50 Hz and mixed are available
Vertical filter
Field memory (181 kbit)
PIP mode: Single PIP with 1/9 or 1/16 size, 6 PIPs with 1/36 size
Flexible PIP position
3ch 8-bit DACs for YUV or RGB outputs
YUV to RGB converter
Others
42 MHz crystal oscillator
I2C bus control
Package: QFP80
Power supply: 3.3 VWeight: 1.6 g (typ.)


Pinout

Connection Diagram


Specifications

Characteristics
Symbol
Rating
Unit
Supply voltage
VDD
VSS to VSS - 4.5
V
Applied voltage
VIN
-0.3 to VDD - 0.3
V
Applied current
IIN
10
V
Power dissipation
PD
1538
°C
Storage temperature
Tstg
55 to +150
mW



Description

TC90A67F is a Picture-in-Picture (PIP) IC including a PIP controller and a PAL/NTSC decoder function on a chip.
TC90A67F has an ADC, a video decoder, a vertical filter, a field memory, DACs and so on, so that it is easy to design a PIP application with the least external components.
